ABB DCS 500B

DCS500 Pin and Parameter list
A 20
EMF_FILT_TC
Parameter of SETTINGS-function block. ( S2/16 )
Filter time constant for calculated EMF before EMF-controller.
513 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 10 U: ms
EARTH.CURR_SEL
Parameter of CONVERTER_PROTECTION-function block. ( S9/16 )
Selection for earth fault monitoring:
0 = DISABLE
1 = ENABLE.
514 FB_P: E2 SC: - HL: 1 LL: 0 D: 0 U: -
EARTH.FLT_LEV
Parameter of CONVERTER_PROTECTION-function block. ( S9/16 )
Earth fault current tripping level in amperes.
515 FB_P: I2 SC: 1 HL: 20 LL: 0 D: 4 U: A
EARTH.FLT_DLY
Parameter of CONVERTER_PROTECTION-function block. ( S9/16 )
The time after the earth fault is activated.
516 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 10 U: ms
SET_I_CONV_A
Parameter of SETTINGS-function block. ( S2/16 )
The nominal current of the converter.
Note: This parameter overwrites the nominal current of the converter defined by
type code resistors !
0 = type code resistors are in use
> 0 = value of this parameter is used.
517 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 0 U: A
SET_U_CONV_V
Parameter of SETTINGS-function block. ( S2/16 )
The nominal voltage of the converter.
Note: This parameter overwrites the nominal voltage of the converter defined by
type code resistors !
0 = type code resistors are in use
> 0 = value of this parameter is used.
518 FB_P: I2 SC: 1 HL: 2000 LL: 0 D: 0 U: V
SET_MAX_BR_TEMP
Parameter of SETTINGS-function block. ( S2/16 )
The tripping level for the converter heat sink temperature monitoring.
Note: This parameter overwrites the max bridge temperature of the converter defined by
type code resistors !
0 = type code resistors are in use
> 0 = value of this parameter is used.
519 FB_P: I2 SC: 1 HL: 150 LL: 0 D: 0 U: C
