ABB DCS 500B

DCS500 Pin and Parameter list
A 37
WRITE_ENABLE_KEY
Parameter of MAINTENANCE-function block. ( S2/16 )
Save the parameter access
This is the key number
1207 FB_P: I2 SC: 1 HL: 1000 LL: 1 D: 358 U: -
WRITE_ENABLE_PIN
Parameter of MAINTENANCE-function block. ( S2/16 )
Save the parameter access
This is the personality identify number. Parameter access is only possible if
WRITE_ENABLE_KEY and WRITE_ENABLE_PIN numbers are equal.
1208 FB_P: I2 SC: 1 HL: 1000 LL: 1 D: 358 U: -
SELECT_OPER.SYST.
Parameter of MAINTENANCE-function block. ( S2/16 )
Select the operation mode of converter:
0 = 6P-SINGLE (6-pulse single mode, default)
1 = 12P-MASTER (12-pulse master mode)
2 = 12P-SLAVE (12-pulse slave mode)
1209 FB_P: E2 SC: - HL: 2 LL: 0 D: 0 U:-
ACTUAL VALUE 1
Input of MAINTENANCE-function block. ( S2/16 )
Pointer to actual value 1 on panel.
1210 FB_I: C4 SC: - HL: 19999 LL: 0 D: 12103 U: -
ACTUAL VALUE 2
Input of MAINTENANCE-function block. ( S2/16 )
Pointer to actual value 2 on panel.
1211 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10501 U: -
ACTUAL VALUE 3
Input of MAINTENANCE-function block. ( S2/16 )
Pointer to actual value 3 on panel.
1212 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10505 U: -
FIELDBUS NODE ADDR
Parameter of MAINTENANCE-function block. ( S2/16 )
In case a field bus module Nxxx-0x is used keep this parameter to default. If a serial link
has to be established please handle this parameter according to the AC70 documentation.
1213 FB_P: I2 SC: 1 HL: 255 LL:1 D: 1 U: -
MACRO_SELECT
Parameter of MAINTENANCE-function block. ( S2/16 )
Select the macros:
0 = NONE (no macro selected)
1 = MACRO 1 (macro 1 selected)
2 = MACRO 2 (macro 2 selected)
3 = MACRO 3 (macro 3 selected)
4 = MACRO 4 (fieldbus macro selected)
1214 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
