ABB DCS 500B

DCS500 Pin and Parameter list
A 50
REFSEL.[IN2]
Input of REF_SEL-function block. ( S4/16 )
Speed reference input which is selected with SEL2-input.
1912 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 11901 U: -
REFSEL.[SEL2]
Input of REF_SEL-function block. ( S4/16 )
Selects the speed reference input IN2 to the output.
1913 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 11902 U: -
REFSEL.[IN3]
Input of REF_SEL-function block. ( S4/16 )
Speed reference input which is selected with SEL3-input.
1914 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 0 U: -
REFSEL.[SEL3]
Input of REF_SEL-function block. ( S4/16 )
Selects the speed reference input IN3 to the output.
1915 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
REFSEL.[ADD]
Input of REF_SEL-function block. ( S4/16 )
Additional speed reference which is added to the output.
1916 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 11904 U: -
REFSEL.[REV]
Input of REF_SEL-function block. ( S4/16 )
Command which changes the sign of the block output.
1917 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
SOFTPOT.[INCR]
Input of SOFT_POT-function block. ( S4/16 )
Used to activate incrementing of output value.
1918 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
SOFTPOT.[DECR]
Input of SOFT_POT-function block. ( S4/16 )
Used to activate decrementing of output value.
1919 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
SOFTPOT.[FOLLOW]
Input of SOFT_POT-function block. ( S4/16 )
Used to make the output to follow actual motor speed.
1920 FB_I: C4 SC: BI HL: 19999 LL:0 D: 0 U: -
SOFTPOT.OHL
Parameter of SOFT_POT-function block. ( S4/16 )
Positive limit of the output
1921 FB_P: I2 SC: SPEED HL: 23000 LL: -23000 D: 5000 U: rpm
SOFTPOT.OLL
Parameter of SOFT_POT-function block. ( S4/16 )
Negative limit of the output.
1922 FB_P: I2 SC: SPEED HL: 23000 LL: -23000 D: -5000 U: rpm
