ABB DCS 600 MultiDrive User Manual

Chapter 4 - Signals and Troubleshooting
DCS 600 Operating Instructions IV F 4 - 9
Code
seven
segm.
display
Text on
LCD of control panel
CDP 312
(or DRIVES WINDOW)
Definition /
Action
Status
signal
(FAULT_WORD_
1/2/3)
Remark
F 42 42 FEX1 FLT
FIELD EXCITER 1 (field supply 1) fault
A fault was found during self-diagnosis of
field exciter.
Check: - Field exciter operation;
change the unit, if necessary;
- Field 1/Field 2 coding O.K.?
9.02 bit 12
(1)
F 43
43 FEX2 FLT
FIELD EXCITER 2 (field supply 2) fault
{See Fault Code F 42}
9.02 bit 13
(1)
F 44
44 NO I/O
Missing input/output (I/O-) board
Check: - Correct selection of SDCS-IOB-2/3
board (see also param. [P 98.08])
- Is +/- 10 V supply available?
- Flat cable connections between
SDCS-CON-2 and SDCS-IOB-2/3
boards.
9.01 bit 7 (1)
F 48 48 MOT2 TEMP
Overtemperature of MOTOR 2
Check: - Parameter setting MOT_2_TEMP_
FAULT_L [P 28.14]
correct?
{See Fault Code
F 6}
9.01 bit 8 (2)
F 50
50 NO C FAN
No CONVERTER FAN supply acknowledge
Depending on type of unit (size):
Size C4 ⇒ Fault signal
F 50
Sizes C1...C3 ⇒ Alarm signal A 126
Check: - Was input for acknowledge
signal DI1 used?
9.02 bit 10 (2)
F 65 65 REVER FLT
Zero current signal not reached within 6.6 ms
Very fast current rise ramp:
- increase parameter 47.07
9.06 bit 0
(3)
F 66 66 CURR DIFF
Current difference in 12-pulse parallel opera-
tion
Check: - Setting of master and slave
current controller
- increase parameter 47.04
9.06 bit 1
(3)
F 67
67 12P COMM
Open 12-pulse fibre optic link (V260) 9.06 bit 2
(3)
F 68
68 SLAVE DIS
Fault of 12-pulse master.
Master tripped by a fault of the 12-pulse slave.
Check: - Fault logger of 12-pulse slave
9.06 bit 3
(3)
