22 ABB industriAl drives DCS880 QuiCk guiDe - 3ADW000480R020122 ABB industriAl drives DCS880 QuiCk guiDe
—
Parameter groups
Summary of parameter groups
Group Contents
Volt, Amps, rpm.
Run-time-type counters, bridge
temperature.
Control status words.
Hardware and firmware information.
Digital inputs, relay outputs.
Analog inputs.
Analog outputs.
Speed/torque selection.
Digital input, Main control word
Ramp, coast.
Analog input, fieldbus
Drive operation limits.
External events, tripping level.
Maintenance.
Temperature measurement, load
curve definition.
Speed supervision settings, signal
filtering and general scaling settings.
Group Contents
Data storage parameters that can be
written to and read from using other
parameters’ source and target
settings.
Local time out.
Fieldbus communication
configuration.
Fieldbus adapter A.
Data sent to fieldbus adapter A to the
master (e.g. PLC).
Data read from fieldbus.
Fieldbus adapter B.
Data sent to fieldbus.
Data read from fieldbus.
Defines the data sent from the drive
Defines the data sent from the DDCS/
groups
Analog tacho, encoder ...
Configuration of the encoder
interface modules.
FENxx
FENxx
configuration
encoder.
e.g. Type code
Language selection; access levels;
macro selection; parameter save and
restore; control board reboot; user
parameter sets; unit selection; data
logger triggering; parameter; user
lock.
Motor settings, autotuning
Input signals
10.01 DI status b0 digital input DI1
b1 digital input DI2
b2 digital input DI3
b3 digital input DI4
b4 digital input DI5
b5 digital input DI6
b15 digital input DIL
12.11 AI1 actual value analog input
12.21 AI2 actual value analog input
Speed control loop
23.03 Speed reference 7 speed reference ramped
90.01 Motor speed for control speed feedback
Armature current control loop
27.02 Used current reference
27.05 Motor current actual value
—
Control loops most wanted signals
Optimization of control loop requires comparison of reference and actual values
