ABB DCS880 Manual

12
H4T hardware
3ADW000803R0101 DCS880 H4T (Tosa) manual en a
H4T hardware
Type code
The type code contains information on the specification and configuration of the unit. The first digits
from left show the basic configuration (e.g. DCS880-S01-2000). The optional selections are given
thereafter on the name plate by plus code. The main selections are described below. Not all selections
are available for all types.
The unit’s basic type code: DCS880-aab-cccc-ddef + plus code
Product family:
DCS880
Product type:
aa
= S0
Standard converter module
= R0
Rebuild kit
= U1
Upgrade kit
= A0
Enclosed converter
Bridge type:
b
= 1
Single bridge (2-Q)
= 2
2 anti-parallel bridges (4-Q)
Module type:
cccc
=
Rated DC current (IP00)
Rated AC voltage:
dd
= 04
100 V
AC
… 415 V
AC
= 05
100 V
AC
… 500 V
AC
(IEC)/525 V
AC
(UL)
= 06
270 V
AC
… 600 V
AC
= 07
315 V
AC
… 690 V
AC
= 08
360 V
AC
… 800 V
AC
= 10
450 V
AC
… 990 V
AC
= 12
540 V
AC
… 1200 V
AC
Power connection:
e
= X
Standard H1 … H7
= L
Left side H8
= R
Right side H8
Revision code:
f
= 0
1
st
generation
= A
H7: fusing adaption due to UL certification
= B
H5/H6: New cooling fan R2E250-RE04-10
Field exciter
configuration:
+0S163
H1 ... H4 without OnBoard field exciter
+S164
H5 and H6 with internal field exciter, supply external
(H5 and H6: 25 A, Rebuild kit: 16 A/25 A)
Fan voltage:
Standard
Size H4
Fan voltage: 230 V/1
-ph
Application
programming:
+S551
Memory unit including drive application programming license
SDCS-DSL-H10:
+S521
1 DCSLink channel, 0 channels optical power link SDCS-DSL-H10
Voltage measurement:
+S185
SDCS-PIN-H51 configured for 20 V
AC
... 100 V
AC
(H6 ... H8)
Control panel:
+0J404
Without control panel
+J428
Daisy-chain option DPI-H01 kit
+J429
Bluetooth control panel ACS-AP-W
The technical data and specifications are valid as of going to press. ABB reserves the right to make
subsequent alterations.

ABB DCS880 Specifications

General

Control Type	Digital
Voltage Range	Up to 1200 V DC
Control Principle	Field-oriented control
Field Supply	Integrated
Communication Protocols	CANopen
Cooling	Air
Protection Class	IP00, IP20, IP21, IP54
Protection Features	Overvoltage, overtemperature, short circuit, earth fault
Rated Voltage	230 to 1200 V DC
Supply Voltage	380 ... 690 V AC
Input Voltage Range	230 to 690 V AC
Control Mode	Speed, Torque
