13 Battery autonomy
13.1 Examples of internal battery autonomy of DPA UPScale S2 ST40 and ST 60
Module type UPScale M 10
UPScale M 20
Module needs at least 48 blocks for full power
or minimum 40 blocks for 16 kW
Internal separate battery configuration Battery autonomy in min. per module
Frame type
Separate battery / module
8 kW
10 kW
12 kW
16 kW
20 kW
UPScale ST 40
max. 80 blocks
up to 2 modules
(1 x 40) x 7 Ah / Module 8 6 5
UPScale ST 40
max. 80 blocks
1 modules ONLY
(1 x50) x 7 Ah / Module 11 8. 7 4
UPScale ST 60
max. 240 blocks
up to 3 modules
(1 x 40) x 7 Ah / Module 8 6 5
UPScale ST 60
max. 240 blocks
up to 3 modules
(2x 40) x 7 Ah / Module 21 15 12 8 5
Internal common battery configuration Battery autonomy in min. for total system power
With 1 module
Module type 1 x UPScale M 10 1 x UPScale M 20
Total system power
8 kW 10 kW 12 kW 16 kW 20 kW
UPScale ST 40 or
UPScale ST 60
1 x (2x 40) x 7 Ah 21 15 12 8 5
UPScale ST 60
2x (1 x50) x 7 Ah 28 21 16 11 8
UPScale ST 60
3 x (1 x 40) x 7 Ah 35 26 21 14 5
UPScale ST 60
3 x (1 x50) x 7 Ah 47 35 28 19 14
UPScale ST 60
4x (1 x50) x 7 Ah 69 52 41 28 21
UPScale ST 60
3 x (2x 40) x 7 Ah 88 66 52 35 5
With 2 modules
Module type 2 x UPScale M 10 2 x UPScale M 20
Total system power
16 kW 20 kW 24 kW 32KW 40 kW
UPScale ST 40 or
UPScale ST 60
1 x (2x 40) x 7 Ah 8 6 5
UPScale ST 60
2x (1 x50) x 7 Ah 11 8 7 4
UPScale ST 60
3 x (1 x 40) x 7 Ah 14 11 8 6 5
UPScale ST 60
3 x (1 x50) x 7 Ah 19 14 11 8 6
UPScale ST 60
4x (1 x50) x 7 Ah 28 21 16 11 8
UPScale ST 60
3 x (2x 40) x 7 Ah 35 26 21 14 5
With 3 modules
Module Type 3 x UPScale M 10 3 x UPScale M 20
Total System Power 24 kW 30 kW 36 kW 48 kW 60 kW
UPScale ST 60
2x (1 x50) x 7 Ah 7 5 4
UPScale ST 60
3 x (1 x 40) x 7 Ah 8 6 5
UPScale ST 60 2x (2x 40) x 7 Ah 12 9 7 5 4
UPScale ST 60
4x (1 x50) x 7 Ah 16 12 10 7 5
UPScale ST 60
3 x (2x 40) x 7 Ah 21 15 12 8 5
