5.5 Internal batteries
5.5.1 Internal battery modules DPA UPScale ST S2 40
There is space for up to 80x 7/9Ah internal batteries in the DPA UPScale ST S2 40 FRAME. Different
battery and system configurations are shown in the drawing below.
NOTE:
For DPA UPScale M-10 kW UPS systems, it is permissible to use 20-50 (only even numbers) 12 V
battery blocks depending the power sourced on the output
For DPA UPScale M-20 kW UPS systems, it is permissible to use 30-50 (only even numbers) 12 V
battery blocks depending the power sourced on the output
IMPORTANT:
For maximum battery autonomies with the corresponding output power range and number of battery
blocks per string, refer to the “battery characteristics” chapter in the technical data sheet.
NOTE: Set up the correct number of battery blocks in the control panel (menu: Service-Set-Up).
DPA UPScale ST S2 40
Module
Module Module Module
(
1x40)x7Ah (1x50)x7Ah (2x40)x7Ah
Fig 5.5.1-1: Internal Battery Modules DPA UPScale ST S2 40
Other combinations are possible - refer to the technical data sheet.
5.5.2 Internal battery modules DPA UPScale ST S2 60
There is space for up to 240 x 7/9Ah internal batteries in the DPA UPScale ST S2 60 frame. Different
battery and system configurations are shown in the drawing below.
NOTE:
For DPA UPScale M-10 kW UPS systems, it is permissible to use 20-50 (only even numbers) 12 V
battery blocks depending the power sourced on the output.
