ABB EL3000 Series - Model EL3040 Electrical Connections

94 EL3000 CONTINUOUS GAS ANALYZERS | CI/EL3000-EN REV. B
Electrical connections Model EL3040
Screwed cable glands
Type Use (Recommendation) Permissible cable diameter
M20
Power supply 5 to 13 mm
M25
Modbus/Profibus 8 to 17 mm (insert 5 x 4 mm)
M25
Network connections 8 to 17 mm
M25
3x analog outputs 8 to 17 mm (insert 3 x 7 mm)
M32
Digital inputs/outputs 12 to 21 mm
M32
Digital inputs/outputs 12 to 21 mm
