16| © 2020 Emax 2 Retrofill Circuit Breakers 600A-4000A 2TSA451011P0000 Rev-B
Figure 39
AK75 , Emax 4.2 3000A
Figure 40
AK100 , Emax 6.2 4000A
Forced cooling (Fans) for 3000A Rating only.
Fans Turn ON at 2500A and OFF at 2300A
For other detail related to Trip unit config and
wiring refer to Fan control section in manual.
