ABB Emax 2 Installation And Maintenance Guide

26| © 2020 Emax 2 Retrofill Circuit Breakers 600A-4000A 2TSA451011P0000 Rev-B
Customize retrofill secondary wiring
Notice
WIRING
 Before installing the breaker, the secondary
disconnects must be wired to the Emax 2 Retrofill
Breaker.
 Wires with wire markers are provided on the
Retrofill. Make sure that the switchgear wiring
connection points match up with the original
wiring of the cubicle. This ensures that all wiring
connections are properly made.
 Wrong connections will cause the breaker to
malfunction.

ABB Emax 2 Specifications

General

Breaking Capacity	Up to 150 kA
Number of Poles	3 or 4
Standards	IEC 60947-2
Rated insulation voltage	1000V AC
Mounting	Fixed, Withdrawable
