ABB Emax 2 Installation And Maintenance Guide

10| © 2020 Emax 2 Retrofill Circuit Breakers 600A-4000A 2TSA451011P0000 Rev-B
AKD - 5, Retrofill Breaker
11 - AKD-5, Breaker Models
The following figures depicts the AKD5 Retrofill breakers (600-4000A)
AKD5
AK25 , Emax 1.2 600A CiC (Cradle in Cradle) Retrofill
Kit
Figure 11 & 12
Fig
1
1.
Emax 1.2 Circuit Breaker
(Moving Portion)
Fig
1
2.
Circuit Breaker
Projected
from Cassette
Figure 13
Retrofill
Kit
Figure 14 & 15
Fig 14. Rear View of Retrofill Kit Fig 15. Front view inside SwitchGear

ABB Emax 2 Specifications

General

Breaking Capacity	Up to 150 kA
Number of Poles	3 or 4
Standards	IEC 60947-2
Rated insulation voltage	1000V AC
Mounting	Fixed, Withdrawable
