54| © 2020 Emax 2 Retrofill Circuit Breakers 600A-4000A 2TSA451011P0000 Rev-B
Configuring Ekip Touch, Hi Touch Trip unit
30 - Connecting Ekip Touch
Figure 99
Connet Ekip Touch or Hi Touch Trip unit using Ekip connect 3.0.357 9 (or later) software and
Ekip T&P unit.
