F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 3 Electrical Installation
OI/FEF/FEV/FEW–EN Rev. D 11
Fig. 3.2 Metal Pipe with Flange Adaptor
Fig. 3.3 Flanged Metal Pipe to Plastic Pipe
Fig. 3.4 Metal Pipe with Plastic Make-up Insert
Plastic Pipe
Metal Pipe
Fluid Contact Ring
Plastic Pipe
Metal Pipe
Fluid Contact Ring
