ABB FEF series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
26 OI/FEF/FEV/FEW–EN Rev. D
DN25
(1 in.)
PN10 to 40 115 (4.53) 200 (7.87) 268 (10.55) 82 (3.23) 193 (7.6) 148 (5.83) 113 (4.45) 9 (20) 7 (15)
JIS5K 95 (3.74)
JIS10K 125 (4.88)
ASME B16.5 CL300 125 (4.88)
ASME B16.5 CL150 108 (4.25)
DN32
(1
1
/4 in.)
PN10 to 40 140 (5.51) 275 (10.83) 92 (3.62) 200 (7.87) 155 (6.10) 113 (4.45) 10 (22) 8 (18)
JIS5K 115 (4.53)
JIS10K 135 (5.31)
ASME B16.5 CL300 135 (5.31)
ASME B16.5 CL150 117 (4.61)
DN40
(1
1
/2 in.)
PN10 to 40 150 (5.91) 11 (24) 9 (20)
JIS5K 120 (4.72)
JIS10K 140 (5.51)
ASME B16.5 CL300 155 (6.10)
ASME B16.5 CL150 127 (5.00)
DN50
(2 in.)
PN10 to 40 165 (6.5) 281 (11.06) 97 (3.82) 206 (8.11) 161 (6.34) 115 (4.53) 12 (26) 10 (22)
JIS5K 130 (5.12)
JIS10K 155 (6.10)
AS4087 PN16 150 (5.91)
AS4087 PN35 165 (6.50)
ASME B16.5 CL150 152 (5.98)
ASME B16.5 CL300 165 (6.50)
DN65
(2
1
/2 in.)
PN10 to 40 185 (7.28) 292 (11.50) 108 (4.25) 217 (8.54) 172 (6.77) 104 (4.09) 13 (29) 11 (24)
JIS5K 155 (6.10)
JIS10K 175 (6.89)
AS4087 PN16 165 (6.50)
AS4087 PN35 185 (7.28)
ASME B16.5 CL150 178 (7.01)
ASME B16.5 CL300 190 (7.48) 15 (33) 13 (29)
DN80
(3 in.)
PN10 to 40 200 (7.87) 292 (11.5) 108 (4.25) 217 (8.54) 172 (6.77) 104 (4.09) 17 (37) 15 (33)
JIS5K 180 (7.09)
JIS10K 185 (7.28)
AS4087 PN16 185 (7.28)
AS4087 PN35 205 (8.07)
ASME B16.5 CL150 190 (7.48)
ASME B16.5 CL300 210 (8.28) 19 (42) 17 (37)
Dimensions in mm (in.) Approx. weight in kg (lb)
DN Mating flange type D L F C E G A Integral Remote
Table 5.1 DN10 to 125 (
3
/8 to 5 in. NB) (FEW) dimensions / weights (Continued)
