ABB FEF series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
OI/FEF/FEV/FEW–EN Rev. D 29
DN250
(10 in.)
PN10 395 (15.55) 450 (17.72) 426 (16.77) 198 (7.80) 351 (13.82) 306 (12.05) 235 (9.62) 61 (134) 59 (130)
PN16 405 (15.94) 65 (143) 63 (139)
PN25 425 (16.73) 84 (185) 82 (180)
PN40 450 (17.72) 95 (209) 93 (205)
AS4087 PN16 405 (15.94) 65 (143) 63 (139)
AS4087 PN35 430 (16.93) 95 (209) 93 (205)
JIS5K 385 (15.16) 65 (143) 63 (139)
JIS10K 400 (15.75)
ASME B16.5 CL300 445 (17.52) 105 (231) 103 (227)
ASME B16.5 CL150 405 (15.94) 70 (154) 68 (150)
DN300
(12 in.)
PN10 445 (17.52) 500 (19.69) 449 (17.68) 449 (17.68) 449 (17.68) 449 (17.68) 449 (17.68) 74 (163) 72 (158)
PN16 460 (18.11) 80 (176) 78 (172)
PN25 485 (19.09) 100 (220) 98 (216)
JIS5K 430 (16.93) 80 (176) 78 (172)
JIS10K 445 (17.52)
AS4087 PN16 455 (17.91)
AS4087 PN35 490 (19.29) 130 (286) 128 (282)
ASME B16.5 CL300 520 (20.47) 150 (330) 148 (326)
ASME B16.5 CL150 485 (19.09) 105 (231) 103 (227)
PN40 515 (20.28) 600 (23.62) 130 (286) 128 (282)
DN350
(14 in.)
PN10 505 (19.88) 550 (21.65) 464 (18.27) 265 (10.43) 389 (15.31) 344 (13.54) 322 (12.68) 95 (209) 93 (205)
PN16 520 (20.47) 110 (242) 108 (238)
PN25 555 (21.85) 145 (319) 143 (315)
JIS5K 480 (18.90) 95 (209) 93 (205)
JIS10K 490 (19.29)
AS4087 PN16 525 (20.67) 130 (286) 128 (282)
AS4087 PN35 550 (21.65) 185 (407) 183 (403)
ASME B16.5 CL300 585 (23.03) 140 (308) 138 (304)
ASME B16.5 CL150 535 (21.06) 105 (231) 103 (227)
PN40 580 (22.83) 650 (25.59) 195 (429) 193 (425)
DN400
(16 in.)
PN10 565 (22.24) 600 (23.62) 506 (19.92) 265 (10.43) 431 (16.97) 386 (15.20) 322 (12.68) 103 (227) 101 (222)
PN16 580 (22.83) 126 (277) 124 (273)
PN25 620 (24.41) 170 (374) 168 (370)
JIS5K 540 (21.26) 103 (227) 101 (223)
JIS10K 560 (22.05) 116 (255) 114 (251)
AS4087 PN16 580 (22.83) 154 (339) 152 (335)
AS4087 PN35 610 (24.02) 302 (664) 300 (660)
ASME B16.5 CL300 650 (25.59) 265 (583) 263 (578)
ASME B16.5 CL150 600 (23.62) 175 (385) 173 (381)
PN40 660 (25.98) 650 (25.59) 258 (568) 256 (564)
Dimensions in mm (in.) Approx. weight in kg (lb)
DN Mating flange type D L F C E G A Integral Remote
Table 5.2 DN150 to 400 (6 to 5 in. NB) (FEW) dimensions / weights (Continued)
