ABB FEF series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
OI/FEF/FEV/FEW–EN Rev. D 35
DN1600
(64 in.)
PN6 1830 (72.05) 2080 (81.89) 1066 (41.96) 865 (34.06) 990 (38.98) 950 (37.4) 1000 (39.37) 1434 (3155) 1432 (3150)
PN10 1915 (75.39) 2525 (5555) 2523 (5551)
PN25 1975 (77.76) 3201 (7042) 3199 (7038)
PN16 1930 (75.98) 2768 (6090) 2766 (6085)
PN40 2025 (79.72) 4375 (9625) 4373 (9621)
DN1650
(66 in.)
AWWA C207 CLASS B 2032 (80.00) 2145 (84.45) 1116 (43.94) 915 (36.02) 1040 (40.94) 1000 (39.37) 1000 (39.37) 1504 (3309) 1502 (3304)
AWWA C207 CLASS D 2032 (80.00) 2025 (4455) 2023 (4451)
DN1800
(72 in.)
PN6 2045 (80.51) 2340 (92.13) 1181 (46.50) 980 (38.58) 1105 (43.50) 1065 (41.93) 1100 (43.31) 1853 (4077) 1851 (4072)
PN10 2115 (83.27) 3180 (6996) 3178 (6992)
PN16 2130 (83.86) 3657 (8045) 3655 (8041)
PN25 2195 (86.42) 4422 (9728) 4420 (9724)
AWWA C207 CLASS B 2197 (86.50) 1773 (3901) 1771 (3896)
AWWA C207 CLASS D 2197 (86.50) 2387 (5251) 2385 (5247)
DN1950
(78 in.)
AWWA C207 CLASS B 2362 (92.99) 2535 (99.80) 1291 (50.81) 1090 (42.91) 1215 (47.83) 1175 (46.26) 1180 (46.46) 2309 (5080) 2307 (5075)
AWWA C207 CLASS D 2362 (92.99) 3037 (6681) 3035 (6677)
DN2000
(80 in.)
PN6 2265 (89.17) 2600 (102.36) 2581 (5678) 2579 (5674)
PN10 2325 (91.54) 4254 (9359) 4252 (9354)
PN16 2345 (92.32) 4556 (10023) 4554 (10019)
PN25 2425 (95.47) 5896 (12971) 5894 (12967)
DN2100
(84 in.)
AWWA C207 CLASS B 2534 (99.76) 2730 (107.48) 1395 (54.91) 1194 (47.01) 1319 (51.93) 1279 (50.35) 1180 (46.46) 2641 (5810) 2639 (5806)
AWWA C207 CLASS D 2534 (99.76) 3487 (7671) 3485 (7667)
DN2200
(88 in.)
PN6 2475 (97.44) 2860 (112.60) 1330 (52.36) 3363 (7399) 3361 (7394)
PN10 2550 (100.39) 5795 (12749) 5793 (12745)
DN2400
(96 in.)
PN6 2685 (105.71 3120 (122.83) 1495 (58.85) 1294 (50.94) 1419 (55.87) 1379 (54.29) 1450 (57.09) 4100 (9020) 4098 (9016)
PN10 2760 (108.66) 6968 (15330) 6966 (15325)
Dimensions in mm (in.)
Approx. weight in kg (lb)
DN Mating flange type D L F C E G A Integral Remote
Table 5.3 DN450 to 2400 (18 to 96 in. NB) (FEW) dimensions / weights (Continued)
