ABB FEF series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
OI/FEF/FEV/FEW–EN Rev. D 37
DN80
(3 in.)
EN1092-1 PN10, PN16 200 (7.87) 200 (7.87) 280 (11.02) 51.5 (2.03) 205 (8.07) 156 (6.14) 61 (2.40) 16 (36) 15 (33)
ASME B16.5 CLASS 150 190 (7.48)
JIS 7.5K 211 (8.31)
JIS 10K 185 (7.28)
AS2129 TABLE C D E 185 (7.28)
AS4087 PN14, PN16 185 (7.28)
AS2129 TABLE F 205 (8.07)
AS4087 PN21 205 (8.07)
DN100
(4 in.)
EN1092-1 PN10, PN16 220 (8.66) 250 (9.84) 320 (12.60) 63.75 (2.51) 245 (9.65) 196.8 (7.75) 70 (2.76) 19 (42) 18 (40)
ASME B16.5 CLASS 150 228.6 (9.00)
JIS 7.5K 238 (9.37)
JIS 10K 210 (8.27)
AS2129 TABLE C D 215 (8.46)
AS4087 PN14, PN16 215 (8.46)
AS2129 TABLE E 215 (8.46)
AS4087 PN21 230 (9.06)
AS2129 TABLE F 230 (9.06)
DN125
(5 in.)
EN1092-1 PN10, PN16 250 (9.84) 250 (9.84) 320 (12.60) 63.75 (2.51) 245 (9.65) 197 (7.76) 70 (2.76) 20 (44) 19 (42)
ASME B16.5 CLASS 150 254 (10.00)
JIS 10K 250 (9.84)
AS2129 TABLE C D E 255 (10.04)
AS2129 TABLE F 280 (11.02)
DN150
(6 in.)
EN1092 PN10, PN16 285 (11.22) 300 (11.81) 340 (13.39) 84.4 (3.32) 265 (10.43) 217 (8.54) 103 (4.06) 32 (70) 31 (68)
ASME B16.5 CLASS 150 279 (10.98)
JIS 7.5k 290 (11.42)
JIS 10K 280 (11.02)
AS2129 TABLE C D 280 (11.02)
AS4087 PN14, PN16 280 (11.02)
AS2129 TABLE E 280 (11.02)
AS2129 TABLE F 305 (12.01)
AS4087 PN21 305 (12.01)
DN200
(8 in.)
EN1092-1 PN10 340 (13.39) 350 (13.78) 365 (14.37) 109.8 (4.32) 290 (11.42) 243 (9.57) 150 (5.91) 49 (108) 48 (105)
EN1092-1 PN16 340 (13.39)
ASME B16.5 CLASS 150 345 (13.58)
JIS 7.5K 342 (13.46)
JIS 10K 330 (12.99)
AS2129 TABLE C D 335 (13.19)
AS4087 PN14, PN 16 335 (13.19)
AS2129 TABLE E 335 (13.19)
AS2129 TABLE F 370 (14.57)
AS4087 PN21 370 (14.57)
Dimensions in mm (in.) Approx. weight in kg (lb)
DN Mating flange type D L F C E G X Integral Remote
Table 5.4 DN40 to 200 (1
1
/2 to 8 in. NB) (FEV) dimensions / weights (Continued)
