ABB FEW series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
32 OI/FEF/FEV/FEW–EN Rev. D
DN800
(32 in.)
JIS 5K 995 (39.17) 1040 (40.04) 654 (25.74) 453 (17.83) 578 (22.76) 538 (21.18) 542 (21.34) 280 (616) 278 (612)
JIS 10K 1020 (40.16) 364 (801) 362 (796)
PN6 975 (38.39) 294 (647) 292 (642)
PN10 1015 (39.96) 406 (893) 404 (889)
PN16 1025 (40.35) 469 (1032) 467 (1027)
AWWA C207 CLASS B 1060 (41.73) 328 (722) 326 (717)
AWWA C207 CLASS D 1060 (41.73) 408 (898) 406 (893)
AS4087 PN16 1060 (41.73) 530 (1166) 528 (1162)
AS2129 TABLE-D 1060 (41.73) 386 (849) 384 (845)
AS2129 TABLE-E 1060 (41.73) 519 (1142) 517 (1137)
PN25 1085 (42.72) 615 (1353) 613 (1349)
PN40 1140 (44.88) 866 (1905) 864 (1901)
AWWA C207 CLASS E 1060 (41.73) 634 (1395) 632 (1390)
AWWA C207 CLASS F 1150 (45.28) 897 (1973) 895 (1969)
AS4087 PN35 1060 (41.73) 751 (1652) 749 (1648)
ASME CL150 SERIES A 1060 (41.73) 700 (1540) 698 (1536)
ASME CL150 SERIES B 940 (37.01) 406 (893) 404 (889)
ASME CL300 SERIES B 1055 (41.54) 933 (2053) 931 (2048
DN900
(36 in.)
JIS 5K 1095 (43.11) 1170 (46.06) 705 (27.7() 504 (19.84) 629 (24.76) 589 (23.19) 570 (22.44) 369 812) 367 (807)
JIS 10K 1120 (44.09) 445 (979) 443 (975)
PN6 1075 (42.32) 390 (858) 388 (854)
PN10 1115 (43.90) 502 (1104) 500 (1100)
PN16 1125 (44.29) 589 (1296) 587 (1291)
AWWA C207 CLASS B 1168 (45.98) 417 (917) 415 (913)
AWWA C207 CLASS D 1168 (45.98) 493 (1085) 491 (1080)
AWWA C207 CLASS E 1168 (45.98) 827 (1819) 825 (1815)
AWWA C207 CLASS F 1270 (50.00) 1150 (2530) 1148 (2526)
AS4087 PN16 1175 (46.26) 706 (1553) 704 (1549)
AS2129 TABLE-D 1175 (46.26) 514 (1131) 512 (1126)
AS2129 TABLE-E 1175 (46.26) 694 (1527) 692 (1522)
PN25 1185 (46.65) 819 (1802) 817 (1797)
PN40 1250 (49.21) 1158 (2548) 1156 (2543)
AS4087 PN35 1185 (46.65) 1044 (2297) 1042 (2292)
ASME CL150 SERIES A 1170 (46.06) 961 (2114) 959 (2110)
ASME CL150 SERIES B 1055 (41.54) 595 (1309) 593 (1305)
ASME CL300 SERIES B 1170 (46.06) 1147 (2523) 1145 (2519)
Dimensions in mm (in.)
Approx. weight in kg (lb)
DN Mating flange type D L F C E G A Integral Remote
Table 5.3 DN450 to 2400 (18 to 96 in. NB) (FEW) dimensions / weights (Continued)
