ABB FEW series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
OI/FEF/FEV/FEW–EN Rev. D 31
DN600
(24 in.)
PN10 780 (30.71) 800 (31.50) 565 (22.24) 361 (14.21) 490 (19.29) 445 (17.52) 469 (18.46) 284 (626) 282 (622)
PN16 840 (33.07) 318 (700) 316 (695)
PN25 845 (33.27) 460 (1012) 458 (1008)
JIS5K 770 (30.31) 275 (605) 273 (600)
JIS10K 795 (31.30) 306 (673) 304 (668)
AS4087 PN16 825 (32.48) 382 (840) 380 (835)
AS4087 PN35 850 (33.46) 452 (994) 450 (990)
ASME B16.5 CL300 915 (36.02) 550 (1210) 548 (1205)
ASME B16.5 CL150 815 (32.09) 425 (935) 423 (930)
PN40 890 (35.04) 890 (35.04) 600 (1320) 598 (1316)
DN700
(28 in.)
JIS 5K 875 (34.45) 910 (35.83) 604 (23.77) 403 (15.87) 528 (20.79) 488 (19.21) 444 (17.48) 216 (475) 214 (471)
JIS 10K 905 (35.63) 282 (620) 280 (616)
PN6 860 (33.86) 225 (495) 223 (491)
PN10 895 (35.24) 303 (667) 301 (662)
PN16 910 (35.83) 337 (741) 335 (737)
AWWA C207 CLASS B 927 (36.50) 249 (548) 247 (543)
AWWA C207 CLASS D 927 (36.50) 280 (616) 278 (612)
AS4087 PN16 910 (35.83) 359 (790) 357 (785)
AS2129 TABLE-D 910 (35.83) 263 (579) 261 (574)
AS2129 TABLE-E 910 (35.83) 337 (741) 335 (737)
PN25 960 (37.80) 471 (10.36) 469 (1032)
PN40 995 (39.17) 586 (1289) 584 (1285)
AWWA C207 CLASS E 927 (36.50) 472 (1038) 470 (1034)
AWWA C207 CLASS F 1035 (40.75) 715 (1573) 713 (1569)
AS4087 PN35 935 (36.80) 539 (1186) 537 (1181)
ASME CL150 SERIES A 925 (36.42) 503 (1107) 501 (1102)
ASME CL150 SERIES B 835 (32.87) 323 (711) 321 (706)
ASME CL300 SERIES B 920 (36.22) 631 (1388) 629 (1384)
DN750
(30 in.)
JIS 5K 945 (37.20) 990 (38.98) 630 (24.79) 429 (16.89) 554 (21.81) 514 (20.23) 444 (17.48) 251 (552) 249 (548)
JIS 10K 970 (38.19) 327 (719) 325 (715)
AWWA C207 CLASS B 984 (38.74) 273 (601) 271 (596)
AWWA C207 CLASS D 984 (38.74) 344 (757) 342 (752)
AS4087 PN16 995 (39.17) 467 (1027) 465 (1023)
AS2129 TABLE-D 995 (39.17) 340 (748) 338 (744)
AS2129 TABLE-E 995 (39.17) 454 (999) 452 (994)
AWWA C207 CLASS E 984 (38.74) 496 (1091) 494 (1087)
AWWA C207 CLASS F 1092 (43.99) 790 (1738) 788 (1734)
AS4087 PN35 1015 (39.96) 663 (1459) 661 (1454)
ASME CL150 SERIES A 985 (38.78) 544 (1197) 542 (1192)
ASME CL150 SERIES B 885 (34.84) 320 (704) 318 (700)
ASME CL300 SERIES B 990 (38.98) 748 (1646) 746 (1641)
Dimensions in mm (in.)
Approx. weight in kg (lb)
DN Mating flange type D L F C E G A Integral Remote
Table 5.3 DN450 to 2400 (18 to 96 in. NB) (FEW) dimensions / weights (Continued)
