FSM4000 ELECTROMAGNETIC FLOWMETER | DS/FSM4000-EN REV. L
41
1
Welded spud
3
Male thread
Figure 29: Adapter for variable process connections DN 3 to 100
Welded spuds
Nominal
diameter
Pressure rating
L
In accordance with DIN 11850
In accordance with ISO 1127
In accordance with SMS
Weight
Ø Da
Ø Di
Series
Ø Da
Ø Di
Series
Ø Da
Ø Di
DN
3 to DN 10
(⅛ bis ⅜”)
See the chapter
titled
Material
loads for process
connections
on
page
13
127 (5.0)
13 (0.51)
10 (0.39)
2
13.5 (0.53)
10.3 (0.41)
1
—
—
0.4 (0.9)
DN
15 (½”) 19
(0.75)
16 (0.63)
21.3 (0.84)
18.1 (0.71)
—
—
0.4 (0.9)
DN 20 (¾”)
132 (5.2)
23 (0.91)
20 (0.79)
26.9 (1.06)
23.7 (0.93)
—
—
0.7 (1.5)
DN
25 (1”)
149 (5.87)
29 (1.14)
26 (1.02)
26.9 (1.06)
23.7 (0.93)
25 (0.98)
22.6 (0.89)
0.7 (1.5)
DN 32 (1 ¼”)
166 (6.54)
34 (1.34)
32 (1.26)
1
33.7 (1.33)
30.5 (1.20)
—
—
1.0 (2.2)
DN
40 (1 ½”)
171 (6.73)
41 (1.61)
38 (1.50)
2
42.2 (1.66)
39 (1.54)
1
38 (1.50)
35.6 (1.40)
1.0 (2.2)
DN 50 (2”)
173 (6.81)
54 (2.13)
50 (1.97)
3
51 (2.01)
47.8 (1.88)
2
51 (2.01)
48.6 (1.91)
1.0 (2.2)
DN
65 (2 ½”)
165
(6.50)
*
70 (2.76)
66 (2.60)
2
70 (2.76)
66 (2.60)
2
63.5 (2.50)
60.3 (2.37)
1.4 (3.1)
250.5
(9.86)
**
DN
80 (3”)
169
(6.65)
*
85 (3.35)
81 (3.19)
76.1 (3.00)
72.9 (2.87)
1
76.1
(3.00)
72.9 (2.87)
2.0 (4.4)
254.5
(10.02)
**
DN
100 (4”)
199
(7.83)
*
104 (4.09)
100 (3.94)
101.6 (4.00)
97.6 (3.84)
2
104 (4.09)
100 (3.94)
2.6 (5.7)
304.5
(11.99)
**
* Old installation length for replacement purposes only. Please observe ordering information.
** New installation length.
