ABB FSM4000 - Page 42

42
FSM4000 ELECTROMAGNETIC FLOWMETER | DS/FSM4000-EN REV. L
—
… Model SE21_
Welded spuds
Nominal
diameter
Pressure rating
L
In accordance with DIN EN ISO 2037
In accordance with DIN 2463
Weight
Ø Da
Ø Di
Ø Da
Ø Di
DN
3 to DN 10
(⅛ bis ⅜”)
See chapter
Material loads for
process
connections
on
page
13
127 (5.0)
12 (0.47)
10 (0.39)
13.5 (0.53)
10.3 (0.41)
0.4 (0.9)
DN
15 (½”) 17.2
(0.68)
15.2 (0.60)
21.3 (0.84)
18.1 (0.71)
0.4 (0.9)
DN 20 (¾”)
132 (5.2)
21.3 (0.84)
19.3 (0.76)
26.9 (1.06)
23.7 (0.93)
0.7 (1.5)
DN
25 (1”)
149 (5.87)
25 (0.98)
22.6 (0.89)
28 (1.10)
25 (0.98)
0.7 (1.5)
DN 32 (1 ¼”)
166 (6.54)
33.7 (1.33)
31.3 (1.23)
35 (1.38)
32 (1.26)
1.0 (2.2)
DN
40 (1 ½”)
171 (6.73)
38 (1.5)
35.6 (1.40)
40 (1.57)
36.8 (1.45)
1.0 (2.2)
DN 50 (2”)
173 (6.81)
51 (2.01)
48.6 (1.91)
52 (2.05)
49 (1.93)
1.0 (2.2)
DN
65 (2 ½”)
165 (6.50)*
63.5 (2.50)
60.3 (2.37)
70
(2.76)
66 (2.60)
1.4 (3.1)
250.5 (9.86)**
DN
80 (3”)
169 (6.65)*
76.1 (3.00)
72.9 (2.87)
85 (3.35)
81 (3.19)
2.0 (4.4)
254.5 (10.02)**
DN
100 (4”)
199 (7.83)*
101.6 (4.00)
97.6 (3.84)
104 (4.09)
100 (3.94)
3.0 (6.6)
304.5 (11.99)**
* Old installation length for replacement purposes only. Please observe ordering information.
** New installation length.
External thread in acc. with ISO 228 / DIN 2999
Nominal
diameter
Pressure rating
L
R
a
Weight
DN
3 to 10
(⅛ to ⅜”)
See the chapter
titled
Material
loads for process
connections
on
page
13
139 (5.47)
⅜”
18 (0.71)
0.4 (0.9)
DN
15 (½”)
139 (5.47)
½”
18 (0.71)
0.4 (0.9)
DN 20 (¾”)
164 (6.46)
¾”
25 (0.98)
0.8 (1.8)
DN
25 (1”)
179 (7.05)
1”
25 (0.98)
0.8 (1.8)
Weld stubs
suitable for OD tubing
Nominal
diameter
Pressure rating
Welded spud size
Di
Da
L
Weight
10 (⅜”)
See the chapter
titled
Material
loads for process
connections
on
page
13
½”
9.40 (0.37)
12.70 (0.70)
127 (5.00)
0.4 (0.9)
15 (½”)
¾”
15.75 (0.62)
19.05 (0.75)
127 (5.00)
0.4 (0.9)
20 (1″)
1”
22.10 (0.87)
25.40 (1.00)
132 (5.20)
0.7 (1.5)
25 (1″)
1”
22.10 (0.87)
25.40 (1.00)
149 (5.87)
1.0 (2.2)
40 (1 ½”)
1 ½”
34.80 (1.37)
38.10 (1.50)
171 (6.73)
50 (2″)
2”
47.50 (1.87)
50.80 (2.00)
173 (6.81)
