Operation Manual / A130-H.. - A140-H..

10 Taking out of operation at short notice / 10.2 Installing the replace-

ment turbocharger

10.2 Installing the replacement turbocharger

To enable you to quickly put an engine back into operation after a turbocharger has sus-

tained damage, ABB Turbocharging recommends having a replacement turbocharger or ap-

propriate spare parts available in storage. The defective turbocharger can be removed and

the replacement turbocharger installed within a short period of time.

u Remove defective turbocharger (see chapter Removing and Installing →28).

u Install replacement turbocharger (see chapter Removing and Installing →28).

u Send the defective turbocharger to an ABB Turbocharging Service Station for inspection

and repair.

10.3 Installing the replacement cartridge group

WARNING

Incorrect handling of a cartridge group

Incorrect handling of a cartridge group can damage the turbocharger and

cause injuries to persons.

u Have repairs to the cartridge group carried out by an ABB Turbocharging

Service Station only.

To enable an engine to be put back into operation quickly after a turbocharger has sustained

damage, ABB Turbocharging recommends having a replacement cartridge group available in

storage. The defective cartridge group can be removed and the replacement cartridge group

installed within a short period of time. A replacement cartridge group is ready for use imme-

diately and includes the complete bearing casing with bearing and a balanced rotor.

The repair of a cartridge group requires special tools and the expertise of an ABB Turbochar-

ging Service Station. The rotating parts rotate extremely quickly, and are sensitive to unbal-

ance.

u Remove defective cartridge group (see chapter Dismantling and fitting →78).

u Install replacement cartridge group (see chapter Dismantling and fitting →78).

u Send the defective cartridge group to an ABB Turbocharging Service Station for inspec-

tion and repair.

Page 105 / 122
