8.15 Installing the compressor casing
Fitting the wall insert and the diffuser
Fig.47: Fitting the wall insert and the diffuser
Product Size Tightening torque [Nm]
A130 M6 8
A135 M6 8
A140 M6 8
Table38: Tightening torque (79041)
1. Always replace the O-ring(77005) (see section Spare parts).
2. Install the wall insert(77000) into the compressor casing.
3. Secure the diffuser(79000) with fixing discs(79040) and screws(79041).
