ABB IRB 7600 Series - Axis 3-4, 3 HAC13063-2 (IRB 7600 - 500;2.3)

8 Spare part / part list
8.3.7. Axis 3-4, 3HAC13063-2 (IRB 7600 - 500/2.3)
3HAC022033-001 Revision: K446
© Copyright 2004-2011 ABB. All rights reserved.
8.3.7. Axis 3-4, 3HAC13063-2 (IRB 7600 - 500/2.3)
Part list
Tube shaft 2,3, 3HAC10509-5
Item Qty Art. number Description Note
102.1 1 3HAC022181-001 Material set ax 4 See table Material
set axis 4,
3HAC022181-001 on
page 443.
102.2 1 3HAC10509-5 Tube shaft 2,3 See table below.
102.3 1 3HAC13062-1 Axis 3 See table Axis 3,
3HAC13062-1 on
page 445.
Item Qty Art. number Description Note
102.2.1 1 3HAC10509-6 Tube shaft 2,55, cast
102.2.2 1 3HAC1383-2 Protection Cover compl.
