B1.2 Description of Parameters
Select the access number or letter, of any of the items in the Main Menu, followed by a CR (RETURN etc), to access its associated
sub-menu. It is not necessary for the parameter to be displayed to select it by number.
✶
Note. The correct security level must be selected in Login parameter below to access certain parameters. See
headings in this description or access notes against individual parameters.
Select the access number or letter of any item in a sub-menu, followed by a CR, to read the value or to change it as necessary.
(CR)s without an access code cycles through a menu continuously without accessing a parameter. All ‘live’ data displayed is
updated each second.
Requires Level 2 access>
Read
Read Flow
Read %
Read Fwd
Read Rev
Read Net
Read Alm
Read Vel
Read Quit
1
1>
2>
3>
4>
5>
6>
7>
Q>
1 >
Disp
Disp Mode
Disp Res
Disp Quit
2
1 > 1
2 > 3
Q >
2 >
Login
Login En
Login Key
Login Key
Login Quit
3
1 > 0
2 >
3 >
Q >
3 >
Main Menu Sub-menus Remarks
Requires Level 2 access>
Requires Level 2 access>
Flowrate in chosen units.
Flowrate as a percentage of range
Accumulated total in forward totaliser *
Accumulated total in reverse totaliser *
Net Total (= Forward minus Reverse) *
Cyclic display of active alarms.
True flow velocity in m/s, or ft/s if flow units are in
Ugal or ft^ 3.
Enter Q (CR) to return to Main Menu or (CR) to cycle around this menu.
* Resettable to zero if Tot ClrEn is set (‘73’ from Main Menu)
Set single, double or multi-line display on terminal.
0 = Single line display.
1 = 2 line display for small displays (default).
2 = New line for each display update (e.g. for printers, data logging, etc.).
Set resolution of flow display. Enter number of decimal places required.
Enter Q (CR) to return to Main Menu, or (CR) to cycle around this menu.
Caution. Do not attempt to modify passwords unless fully
conversant with the operation of the menu system.
Shows current security level (0 = default). Enter password for level required.
‘usee’ = Default for Level 1
‘engineer’ = Default for Level 2
Enter new password to replace existing level 1 word
.
Enter new password to replace existing level 2 word
.
Enter Q (CR) to return to Main Menu or (CR) to cycle around this menu.
Note. Access level selected is reset to Level 0 after a ‘Quit’ from Main Menu.
