Slave protocol
F4F Westinghouse, No gateway support
Modbus RTU (CPI)
5.2.2 HSI features
The following table lists the SYS 600C HSI features.
Table 5.3: User interface options
ValueDescriptionUser interface
option
0...10This is the number of workplaces that are in use simultan-
eously. The number of workplaces needed is defined in
the following way: - A workplace means a computer (PC,
Laptop, PDA, ThinClient), which can have one or several
physical screens from where ONE person at a time can
operate. - Several Application Windows can be used in
one workplace.
Nr of Pro work-
places
Yes/NoSelect this option, if you want to use Process Displays in
the workplaces. Process Displays means displays with
zooming, panning, and decluttering functions typically
used to present the primary process, for example, single-
line diagram.
Process displays
Yes/NoSelect this option, if you want to use dynamic network
coloring in the Process Displays.
Network coloring
Yes/NoSelect this option, if you want to use the Trend displays
in the Workplaces.
Trends
Yes/NoSelect this option, if you want to use the Event List dis-
plays in the Workplaces.
Event list
Yes/NoSelect this option, if you want to use the Alarm List dis-
plays in the Workplaces.
Alarm list
Yes/NoSelect this option, if you want to use the Blocking List
displays in the Workplaces.
Blocking list
Yes/NoSelect this option, if you want to use the Measurement
Report displays in the Workplaces.
Measurement re-
ports
This option requires the History Data Logging option.
Yes/NoSelect this option, if you want to integrate PCM600 Tools
in the Process Displays.
PCM600 interface
Yes/NoSelect this option, if you want to integrate LIB 510/542
IED Tools in the Workplace.
LIB 510/542 IED
Tools
If you use only the IED tools in the Workplace, no other
LIB license in needed.
