ABB ProcessMaster FEP610 - Ambient Temperature as a Function of Measuring Medium Temperature

ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 79
12.2.2 Ambient temperature as a function of measuring medium temperature
Integral mount design
Liner material Flange material Ambient temperature range (T
amb.
) Measuring medium temperature range (T
medium
)
Minimum Maximum Minimum Maximum
Hard rubber Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F)
-5 °C (23 °F)
1)
85 °C (185 °F)
2)
80 °C (176 °F)
1)
Hard rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F)
-5 °C (23 °F)
1)
85 °C (185 °F)
2)
80 °C (176 °F)
1)
Soft rubber Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 60 °C (140 °F)
Soft rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F) 60 °C (140 °F)
PTFE Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 85 °C (185 °F)
-10 °C (14 °F) 30 °C (86 °F) -10 °C (14 °F) 130 °C (266 °F)
PTFE Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 85 °C (185 °F)
-20 °C (-4 °F) 30 °C (86 °F) -25 °C (-13 °F) 130 °C (266 °F)
PFA Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 85 °C (185 °F)
-10 °C (14 °F) 30 °C (86 °F) -10 °C (14 °F) 130 °C (266 °F)
PFA Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 85 °C (185 °F)
-20 °C (-4 °F) 30 °C (86 °F) -25 °C (-13 °F) 130 °C (266 °F)
ETFE Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 85 °C (185 °F)
-10 °C (14 °F) 30 °C (86 °F) -10 °C (14 °F) 130 °C (266 °F)
ETFE Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 85 °C (185 °F)
-20 °C (-4 °F) 30 °C (86 °F) -25 °C (-13 °F) 130 °C (266 °F)
1) For China production site only.
2) The maximum measuring medium temperature is reduced to 80 °C (176 °F) for design level "B" sensors with a hard rubber liner.
Remote mount design
Liner material Flange material Ambient temperature range (T
amb.
) Measuring medium temperature range (T
medium
)
Minimum Maximum Minimum Maximum
Hard rubber Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F)
-5 °C (23 °F)
1)
90 °C (194 °F)
2)
80 °C (176 °F)
1)
Hard rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F)
-5 °C (23 °F)
1)
90 °C (194 °F)
2)
80 °C (176 °F)
1)
Soft rubber Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14 °F) 60 °C (140 °F)
Soft rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F) 60 °C (140 °F)
PTFE Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14 °F) 130 °C (266 °F)
PTFE Stainless steel -25 °C (-13 °F) 60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
PFA Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14 °F) 130 °C (266 °F)
PFA Stainless steel -25 °C (-13 °F) 60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
ETFE Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14 °F) 130 °C (266 °F)
ETFE Stainless steel -25 °C (-13 °F) 60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
1) For China production site only.
2) The maximum measuring medium temperature is reduced to 80 °C (176 °F) for design level "B" sensors with a hard rubber liner.
