ABB ProcessMaster FEP610 - Overview Parameter Settings (Factory Default Settings)

ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 93
13.4 Overview parameter settings (factory default settings)
Parameter Possible parameter settings Factory default settings
Sensor Tag Alphanumeric, max. 20 characters None
Sensor Location Tag Alphanumeric, max. 20 characters None
Qv Max 1 Depending on nominal diameter of the flowmeter
sensor.
Set to Q
max
DN according to chapter "Measuring
range table" on page 37.
Unit Volumeflow Qv l/s; l/min; l/h; ml/s; ml/min; m3/s; m3/min; m3/h;
m3/d; hl/h; g/s; g/min; g/h; kg/s; kg/min; kg/h;
kg/d; t/min; t/h; t/d
l/min
Unit Vol. Totalizer m3; l; ml; hl; g; kg; t Liter (l)
Pulses per Unit 1 ... 10000 1
Pulse Width 0,1 ... 2000 ms 100 ms
Damping 0,02 ... 60 s 1
Operating mode digital output 41 / 42 Off, binary output, pulse output, frequency
output
Digital output 41 / 42 as pulse output for forward
flow and reverse flow.
Operating mode digital output 51 / 52 Off, binary output, pulse output (follows digital
output 41 / 42, 90° or 180° phase shift)
Digital output 51 / 52 as binary output for flow
direction.
Curr.Out 31 / 32 4-20mA FWD/REV, 4-20mA FWD, 4-12-20 mA 4-20mA FWD/REV
Curr.Out at Alarm High Alarm 21 ... 23 mA oder Low Alarm
3.5 ... 3.6 mA
High Alarm, 21.8 mA
Current at flow > 103 % (I=20,5 mA) Off (Current output remains at 20.5 mA), High
Alarm, Low Alarm.
Off
Low flow cut-off 0 ... 10 % 1 %
Empty conduit detector On / Off Off
