ABB rec670 Commissioning Manual

IEC 61850 ANSI Function description Bay control
REC670
REC670 (A30) REC670 (A31) REC670 (B30)
REC670 (C30)
LOCREMCTRL LHMI control of PSTO 1+5/APC30 1 1 1 1+5/
APC3
0
TR1ATCC 90 Automatic voltage control
for tap changer, single
control
0-4
1-H11 1-H11 1-H11 2-H16
TR8ATCC 90 Automatic voltage control
for tap changer, parallel
control
0-4
1-H15 1-H15 1-H15 2-H18
TCMYLTC 84 Tap changer control and
supervision, 6 binary
inputs
0-4
4 4 4 4
TCLYLTC 84 Tap changer control and
supervision, 32 binary
inputs
0-4
4 4 4 4
SLGAPC Logic rotating switch for
function selection and
LHMI presentation
15
15 15 15 15
VSGAPC Selector mini switch 20 20 20 20 20
DPGAPC Generic communication
function for Double Point
indication
16
16 16 16 16
SPC8GAPC Single point generic control
8 signals
5 5 5 5 5
AUTOBITS AutomationBits, command
function for DNP3.0
3 3 3 3 3
SINGLECMD Single command, 16
signals
4 4 4 4 4
I103CMD Function commands for
IEC 60870-5-103
1 1 1 1 1
I103GENCMD Function commands
generic for IEC
60870-5-103
50
50 50 50 50
I103POSCMD IED commands with
position and select for IEC
60870-5-103
50
50 50 50 50
I103POSCMDV IED direct commands with
position for IEC
60870-5-103
10
10 10 10 10
I103IEDCMD IED commands for IEC
60870-5-103
1 1 1 1 1
I103USRCMD Function commands user
defined for IEC
60870-5-103
1
1 1 1 1
Secondary system
supervision
CCSSPVC 87 Current circuit supervision 0-5 1 1 2 3
Table continues on next page
Section 3 1MRK 511 360-UEN A
Available functions
32 Bay control REC670 2.1 IEC
Commissioning manual
