10.2 Electro Magnetic Compatibility
All relevant tests according to the standard IEC 60255, EN 61000 respectively to the
new product standard EN 50263
10.2.1 Emission test
Port Frequency range Limits Basic
standard
Test proce-
dure
Remarks
Enclosure 30 - 230 MHz 40 dB(µV/m) quasi peak,
measured at 10 m dis-
tance
EN 55022 EN 55022
See note 1
See note 2
230 - 1000 MHz 47 dB(µV/m) quasi peak,
measured at 10 m dis-
tance
Power Supply 0.15 - 0,50 MHz 79 dB(µV) quasi peak,
66 dB(µV) average
EN 55022 EN 55022
See note 1
0.5 - 5 MHz 73 dB(µV) quasi peak,
60 dB(µV) average
5 MHz - 30 MHz 73 dB(µV) quasi peak,
60 dB(µV) average
NOTE 1 The test procedure given in EN 55022 will be superseded by that given in EN 60255-25 when
it is published.
NOTE 2 May be measured at other distances. When this is done the test report should record the dis-
tance and the circumstances of the measurement. For test site measurements, an inverse proportionality
factor of 20 dB per decade should be used to normalise the measured data to the specified distance for
determining compliance.
