6.2.1.3 Shunt resistor unit REX062
GUID-F16BA87E-7744-4236-BC98-4EBB3FF576A9 v2
Front view
Bottom view
X1
ABB
(235 mm)
(217 mm)
P1
Module Slot Terminal
SRM P1 X1
REX062
1MRK002556-BA-1-PG V2 EN-US
Figure 37: Designation for shunt resistor unit casing
Protective conductor terminal. For connection of the external protective (earth) conductor.
Section 6 1MRK 514 026-UEN B
Connecting
62 670 series 2.2 IEC
Installation manual
