ABB REM615 A User Manual

Parameter Values (Range) Unit Step Default Description
Auto wait time 0...60000 ms 10 2000 Wait time for reclosing condition fullfilling
Auto lockout reset 0=False
1=True
1=True Automatic lockout reset
Protection crd limit 1...5 1 Protection coordination shot limit
Protection crd mode 1=No condition
2=AR inoperative
3=CB close manual
4=AR inop, CB man
5=Always
4=AR inop, CB
man
Protection coordination mode
Auto initiation cnd 1=Not allowed
2=When sync fails
3=CB
doesn't close
4=Both
2=When sync fails Auto initiation condition
Tripping line 0...63 0 Tripping line, defines INIT inputs which
cause OPEN_CB activation
Control line 0...63 63 Control line, defines INIT inputs which
are protection signals
Enable shot jump 0=False
1=True
1=True Enable shot jumping
CB closed Pos status 0=False
1=True
0=False Circuit breaker closed position status
Fourth delay in SOTF 0=False
1=True
0=False Sets 4th delay into use for all DEL_INIT
signals during SOTF
First reclose time 0...300000 ms 10 5000 Dead time for CBB1
Second reclose time 0...300000 ms 10 5000 Dead time for CBB2
Third reclose time 0...300000 ms 10 5000 Dead time for CBB3
Fourth reclose time 0...300000 ms 10 5000 Dead time for CBB4
Fifth reclose time 0...300000 ms 10 5000 Dead time for CBB5
Sixth reclose time 0...300000 ms 10 5000 Dead time for CBB6
Seventh reclose time 0...300000 ms 10 5000 Dead time for CBB7
Init signals CBB1 0...63 0 Initiation lines for CBB1
Init signals CBB2 0...63 0 Initiation lines for CBB2
Init signals CBB3 0...63 0 Initiation lines for CBB3
Init signals CBB4 0...63 0 Initiation lines for CBB4
Init signals CBB5 0...63 0 Initiation lines for CBB5
Init signals CBB6 0...63 0 Initiation lines for CBB6
Init signals CBB7 0...63 0 Initiation lines for CBB7
Blk signals CBB1 0...63 0 Blocking lines for CBB1
Blk signals CBB2 0...63 0 Blocking lines for CBB2
Blk signals CBB3 0...63 0 Blocking lines for CBB3
Blk signals CBB4 0...63 0 Blocking lines for CBB4
Blk signals CBB5 0...63 0 Blocking lines for CBB5
Blk signals CBB6 0...63 0 Blocking lines for CBB6
Blk signals CBB7 0...63 0 Blocking lines for CBB7
Table continues on next page
1YHT530004D05 D Section 9
Control functions
615 series 723
Technical Manual
