ABB REM615 A User Manual

3.14.9.4 Settings
Table 149: SPCGGIO Non group settings
Parameter Values (Range) Unit Step Default Description
Loc Rem restriction 0=False
1=True
1=True Local remote switch restriction
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 1
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 2
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 3
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 4
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 5
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 6
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 7
Generic control point description
Table continues on next page
Section 3 1YHT530004D05 D
Basic functions
136 615 series
Technical Manual

ABB REM615 A Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Communication Protocols	IEC 61850, Modbus, DNP3
Product Type ID	REM615
Protection Functions	Overcurrent, Earth Fault, Thermal Overload
Operating Temperature	-25 to +55 °C
Product Name	REM615 A
Rated Voltage	100-240 V AC/DC
Number of Binary Outputs	6
Input Voltage	24-250 V DC
Enclosure	IP54
Weight	2.5 kg
Mounting	Flush mounting
