9.1.6.3 CBXCBR Output signals
Table 650: CBXCBR Output signals
Name Type Description
SELECTED BOOLEAN Object selected
EXE_OP BOOLEAN Executes the command for
open direction
EXE_CL BOOLEAN Executes the command for
close direction
OP_REQ BOOLEAN Open request
CL_REQ BOOLEAN Close request
OPENPOS BOOLEAN Signal for open position of
apparatus from I/O
CLOSEPOS BOOLEAN Signal for close position of
apparatus from I/O
OKPOS BOOLEAN Apparatus position is ok
OPEN_ENAD BOOLEAN Opening is enabled based on
the input status
CLOSE_ENAD BOOLEAN Closing is enabled based on
the input status
9.1.6.4 DCXSWI Output signals
Table 651: DCXSWI Output signals
Name Type Description
SELECTED BOOLEAN Object selected
EXE_OP BOOLEAN Executes the command for
open direction
EXE_CL BOOLEAN Executes the command for
close direction
OPENPOS BOOLEAN Apparatus open position
CLOSEPOS BOOLEAN Apparatus closed position
OKPOS BOOLEAN Apparatus position is ok
OPEN_ENAD BOOLEAN Opening is enabled based on
the input status
CLOSE_ENAD BOOLEAN Closing is enabled based on
the input status
9.1.7 Settings
9.1.7.1 CBXCBR Non group settings
1MRS758755 C
Control functions
REC615 & RER615
Technical Manual
635
