ABB RER615 Technical Manual

Name Type Values (Range) Unit Description
SUC_RECL BOOLEAN
0=False
1=True
Indicates a suc-
cessful reclosing
sequence
UNSUC_CB BOOLEAN
0=False
1=True
Indicates an un-
successful CB
closing
CNT_SHOT1 INT32 0...2147483647 Resetable oper-
ation counter,
shot 1
CNT_SHOT2 INT32 0...2147483647 Resetable oper-
ation counter,
shot 2
CNT_SHOT3 INT32 0...2147483647 Resetable oper-
ation counter,
shot 3
CNT_SHOT4 INT32 0...2147483647 Resetable oper-
ation counter,
shot 4
CNT_SHOT5 INT32 0...2147483647 Resetable oper-
ation counter,
shot 5
COUNTER INT32 0...2147483647 Resetable opera-
tion counter, all
shots
SHOT_PTR INT32 1...7 Shot pointer val-
ue
MAN_CB_CL BOOLEAN
0=False
1=True
Indicates CB
manual closing
during reclosing
sequence
SOTF BOOLEAN
0=False
1=True
Switch-onto-
fault
DARREC Enum
1=on
2=blocked
3=test
4=test/blocked
5=off
Status
9.4.10 Technical data
Table 691: DARREC Technical data
Characteristic Value
Operate time accuracy ±1.0 % of the set value or ±20 ms
1MRS758755 C Control functions
REC615 & RER615
Technical Manual
689
