ABB | SACE Emax 2
58 | © 2013 ABB | 1SDH001000R0002 - L7804
Ekip Touch protection release | 1 - Layout of the interface
Diagnosis bar.
The diagnosis bar is present in the main page and the level 2 pages, along the lower side of
the display, and has two functions:
• Show the messages present.
• Open the page Alarm List.
NOTE: the diagnosis bar is not present in the menus or in the pages accessible from
these
The bar appears as follows:
TC disconnected
Figure 66
The following table provides a description of the various areas of the bar:
Pos. Description
A
It shows the type of message:
•
Alarm.
•
Warning, error, or prealarm.
•
Information.
•
Active delay.
B It displays the messages alternatively, and in succession.
C ABB logo.
The Alarm List it can be opened, if there are messages, by touching the diagnosis bar in the
message display area (on the display, at the bottom left).
