Wiring diagrams
Wiring diagrams for SAM600-VT can be found in document 1KHL511911.
Connector descriptions
Table 10 lists the interface descriptions for the SAM600-VT module.
Table 10: Interfaces for SAM600-VT
Interface Connector Pin Remark
Power supply interface X1/X2
Power supply - VDC X1 1
Power supply +24 VDC
(main power)
X1 2
Power supply - VDC X1 3
Power supply - VDC X2 1
Power supply +24 VDC
(redundant power)
X2 2
Power supply - VDC X2 3
Digital interface X10
Test switch indication X10 1
Fuse failure phase 1 X10 2
Fuse failure phase 2 X10 3
Fuse failure phase 3 X10 4
Binary input of common
GND
X10 5
Shielding GND X10 6
Shielding GND X10 7
Analog inputs X20
Voltage phase L1- X20 1
Voltage phase L1+ X20 2
Voltage phase L2- X20 3
Voltage phase L2+ X20 4
Voltage phase L3- X20 5
Voltage phase L3+ X20 6
Voltage phase N- X20 7
Voltage phase N+ X20 8
Optical network
interface
X101/X102
IEC/UCA 61850-9-2LE
process bus/system bus
X101 NA SFP cage for optional
100Base-FX SFP module
IEC/UCA 61850-9-2LE
process bus/system bus
X102 NA SFP cage for optional
100Base-FX SFP module
Electrical network
interface
X103/X104
IEC/UCA 61850-9-2LE
process bus/system bus
X103 NA 100Base-TX
IEC/UCA 61850-9-2LE
process bus/system bus
X104 NA 100Base-TX
