ABB SE21 series User Manual

4 Assembly and Installation
D184B122U02 S4 11
4.3 Installation Examples
Fig. 2: Mounting Recommendations for Cluster Mounting
min. 62
min. 175
Opening the housing cover
– Loosen the cover screws
– Remove cover or flip open cover with window
Closing the housing cover
– Press the cover with the window on the side with the cover
screws against the gasket and tighten the screws
– Set the small cover on the frame and tighten the screws
