9.14 Replaceable Parts List Converter
Fig. 29: Replaceable Parts Converter
No. Description Part No.
1
2
3
4
5
6
7
8
9
10
11
Driver Board
Front End Board
Digital-I/O Board Standard
Digital-I/O Board HART
Digital-I/O Board PROFIBUS PA
Power Supply Board Standard U
High voltage
Power Supply Board Standard U
Low voltage
Bracket
Display board
Mach. screw, Phillps, phillister head DIN 7985 M4x12 SS
Spring washer B 4.0 DIN 127 SS
Mach. screw, Phillps, phillister head DIN 7985 M3x12 SS
Spring washer B 3.0 DIN 127 SS
Converter module type tag
D685A1016U01
D685A1017U01
D685A1018U01
D685A1018U02
D685A1032U01
D685A1019U01
D685A1019U02
D353F151U01
D685A1015U01
D396A014U02
D004F109AU20
D004F109AU20
D085C016BU20
D338C706U01
Y
Y
7,8
6
Y- Y
9,10
11
5
4
1
2
3
1:2
10pole Plug from
display board plugged in.
TTL Plug
Module type
tag
