ABB SE21 series - Messages and Tests

9 Maintenance
50 S4 D184B122U02
9.8 Messages and Tests
9.8.1 Overview of the Error Conditions and Alarms
Error Code and Clear
Text Message
Flowrate
Display
Messages While
Simulating
Current Output
Current Output Pulse
Output
Contact Output Message with
HART
General
Alarm
Min-
Alarm
Max-
Alarm
Max/Min-
Alarm
Empty
Pipe
0 =„Empty pipe“ 0 % – Prog.Al. DLR 0 % Alarm Alarm More Stat avai.
1 =„AD-Converter/DSP“ 0 % – Prog.Al. 0 % Alarm Trans Mal F.
2 =„Driver“ 0 % – Prog.Al. 0 % Alarm Trans Mal F.
3 =„Flowrate >105 %“ 105 % Yes High.Al 105 % Alarm PV out Limits
4 =„Ext. Zero Return“ 0 % – 0 % 0 % Alarm More Stat avai.
5 =„Database“ 0 % Yes Prog.Al. 0 % Alarm Trans Mal F.
6 =„Totalizer“ – Yes – – Alarm More Stat avai.
A =„Max-Alarm“ – Yes – – Alarm Alarm Alarm More Stat avai.
B =„Min-Alarm“ – Yes – – Alarm Alarm Alarm More Stat avai.
C =„ext. Database“ 0 % Yes Prog.Al. 0 % Alarm Trans Mal F.
F =„FRAM in Pri.“ 0 % Yes Prog.Al. 0 % Alarm Trans Mal F.
D =„OLD PRIMARY“ 0 % Yes Prog.Al. 0 % Alarm Trans Mal F.
