ABB SE21 series - Page 33

D184B122U02 S4 33
Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Display 1st line
FB TOT1 Total Here the Total-Value of the
Totalizer-Block is displayed. The displayed
unit is the UNIT_TOTAL.
FB TOT1 Status Here the Actual-Mode of
the particular Block and the Status of the
Output-Variables (Total. Status) is dis-
played. After the Status, if required, the
Substatus is displayed as a number. Exam-
ple BAD 3 indicates that the Status is BAD,
Substatus is 3 = device failure.
FB TOT2 Total Here the Total-Value of the
Totalizer-Block is displayed. The displayed
unit is the UNIT_TOTAL.
FB TOT2 Status Here the Actual-Mode of
the particular Block and the Status of the
Output-Variables (Total. Status) is dis-
played. After the Status, if required, the
Substatus is displayed as a number. Exam-
ple BAD 3 indicates that the Status is BAD,
Substatus is 3 = device failure.
For descriptions of the number codes see
the Data Link documentation.
FB TOT1 Total
Display 2nd line
same as 1st display
line
Selections for the 2nd display line
Q [Percent]
Display 3rd line
same as 1st display
line
No selections possible when the display
mode is 1 big, 1 small
Q [Percent]
Display 4th line
same as 1st display
line
No selections possible when the display
mode is 1 big, 1 small
Q [Percent]
Contrast
Set the contrast for the display for the local
ambient conditions, STEP = darker;
DATA = lighter.
Information!
Adjust the display contrast so that the dis-
play always remains readable.
Submenu
Alarm
Min. Alarm
numeric entry
0% – Max. Alarm
Range for the Min. Alarm
0% – Max. Alarm (= flow range setting). Set
in 1 % steps, switching hysteresis 1 %.
ENTER 0 %
Max. Alarm
numeric entry
Min. Alarm – 105%
Range for the Max. Alarm
Min. Alarm –105% of the flow range setting.
Set in 1 % steps, switching hysteresis 1 %.
100 %
