ABB Terra 24 - Technical Data

TERR A DC WA LLBOX
2023 -20-06 35/ 40
8 Technical Data
8.1 Electrical data
AC Input
AC input voltage range
208 - 240 V
AC
+/- 10% (60Hz)
AC input power connection
1-phase, 208-240 V
AC
: L1, L2, GND
Maximum rated input current at nominal voltage
100 A
Recommended upstream overcurrent protection
device rating
125 A
Power factor
> 0.96
Efficiency
94% at nominal output power
DC output
Maximum DC output power
19.5 kW @ 208 V
22.5 kW @240 V
DC output voltage range
CCS1: 150 - 920 VDC
CHAdeMO: 150 – 500 VDC
Maximum DC output current
60 ADC
(1) Single phase configuration
General
DC connection standard
EN61851-23 / DIN 70121 CCS 2 CHAdeMO 1.0
DC cable length
3.5 meters or 7 meters (12 feet or 23 feet)
DC plug type
CCS 1 / CHAdeMO
RFID data
ISO/IEC14443A/B, ISO/IEC15693, NFC reader
mode, Mifare, Calypso
RFID system
FeliCa™1, NFC reader mode
Network connection
GSM / 4G modem
10/100 Base-T Ethernet
