ABB Terra 24 - Mechanical Data; Environment; Certifications

TERR A DC WA LLBOX
2023 -06-20 35/39
8.2 Mechanical data
Mechanical data
Dimensions (H x W x D)
770 mm x 585 mm x 300 mm / 30.32” x 23.03” x
11.81”
Weight
70 kg / 154.32lbs
Volume
0,135 m
3
Dimensions including packaging (H X W
x D)
650 mm x 1200 mm x 800 mm /25.6” x 47.25” x
31.5”
Weight including packaging
80 kg / 176.37 lbs.
Mechanical impact protection
IK10
8.3 Environment
Environmental data
Ingression protection
IP54, NEMA 3S; indoor and outdoor
Temperature range – Operation
-35°C to + 55°C /-31F to + 131F (derating
applies between 45°C and 55°C / 113F-131F)
Temperature range - Storage
-40 °C to +70 °C / -40F to +158F
Humidity
20% - 95% RH - non-condensing
Operational noise level
55 dBA @25°C
Altitude
2500 m max.
8.4 Certifications
EMC: EN 61000-6-4 Class A emission; EN 61000-6-3 Class B emission; EN 61000-6-2 immunity.
LVD: IEC 61851-23, IEC 61851-1, IEC 62196, IEC 60950, EN 61010, EN 60335 (see certificates)
RFID: ETSI EN 300 330
• UL 2202
• CSA STD C22.2 No. 107.1
• FCC Part 15 Class A
