ABB Terra 24 - Safety Signs and Warnings; Hazard Identification

TERR A DC WA LLBOX
2023 -20-06 7/ 40
ABB6AGC107314
TWB UL 24 CJ 7M-7M-0-0
ABB6AGC109857
TWB UL 24 CJ 3M-7M-0-0
Optional connector holsters shown below may be purchased separately with the order code details shown below.
Charging cable type
ABB order code
CCS-1
ABB6AGC076604
CCS-1 (*)
ABB6AGC109619
CHAdeMO
ABB6AGC076601
(*) CCS-1 optional holster to be use in combination with products:
ABB6AGC107060
TWB UL 24 C 7M-7M-0-0
ABB6AGC107059
TWB UL 24 C 3M-7M-0-0
ABB6AGC107314
TWB UL 24 CJ 7M-7M-0-0
ABB6AGC109857
TWB UL 24 CJ 3M-7M-0-0
1.4 Signs
The following signs are used on the equipment and in this manual:
DANGER
Hazardous voltage
Identifies a hazard that could result in severe injury or death through elec-
trocution.
WARNING
Various
Identifies a hazard that could result in severe injury or death.
WARNING
Rotating parts
Identifies a hazard that could result in injury due to the presence of rotat-
ing or moving parts.
