Operation Manual / TPL65-A10 / -A30
5 Maintenance / 5.2 Cleaning the filter silencer
© Copyright 2020 . All rights reserved. HZTL2482_EN Rev.E March 2020
u Join connecting rods (81269) using screws (81272). When tightening
the screws (81272), ensure that connecting rods (81269) are located
correctly in recesses in filter silencer body (81135). Now tighten
screws (81272) alternately until the following maximum torque is
reached:
Screw Tightening torque [Nm]
81272 20
u Screw lock nuts (81273) onto screw (81272) and tighten to following
torque:
Lock nut Tightening torque [Nm]
81273 40
If provided
u Fit filter strip (81265).
Page 51 / 117
