ABB TPL65VA33 - Page 121

Operation Manual / TPL65VA32/33
Spare parts
12
View of cartridge group with part
numbers
12.3
Page 119
© Copyright 2015 ABB. All rights
reserved.
September 2015 HZTL2464_EN Revision C
Part number
Description
21000 Shaft
25000
Compressor wheel
32001 Thrust bearing
32101
Radial bearing at compressor end
32102 Radial bearing at turbine end
32104
Auxiliary bearing
32105 Floating disc
32106
Axial bearing
32107 Bearing bush
42001
Bearing casing
42002 Hood
42011
O-ring
42015 Sealing cover
42041 (in customer spare part set)
Gasket
42045 (in customer spare part set) Gasket
42058 (in customer spare part set)
Verbus Ripp® Washer
42059 (in customer spare part set) Hexagon-head screw
42063
Verbus Ripp® Washer
42064 Hexagon-head screw
43002 (option with compressor wheel
cooling system)
Plate
43001 Partition wall
43005
O-ring
43006 O-ring
43007
O-ring
86505 Speed sensor
86506 (in customer spare part set)
O-ring
