ABB TPL65VA33 - Installing the Turbocharger

Operation Manual / TPL65VA32/33
Removal and installati
on
7
Installing the turbocharger
7.3
Page 78
© Copyright 2015 ABB. All rights reserved.
September 2015 HZTL2464_EN Revision C
Installing the turbocharger
7.3
 Remove cover from oil connection.
 Inspect lifting gear.
 Fasten separate lifting gear to each of two bearing casing ribs
provided for this purpose.
CAUTION
Oil orifice plates
An orifice plate for adjusting the oil pressure is fitted in each of the two
oil inlet channels in the bearing casing. When the cartridge group, the
bearing casing or the turbocharger is fitted to the engine, it must be
ensured that the orifice plates that are specified for the turbocharger
have been installed in the two oil inlet channels.
 Check correct installation of oil orifice plates.
 Adapt turbocharger to suit engine.
 Tighten fixing screws in foot in accordance with engine builder's
instructions.
 Fasten gas, air and oil lines in accordance with engine builder’s
instructions.
TPL65: Version with compressor wheel cooling system
 Fit air supply line. (See also chapter Preliminary remarks / Layout and
functioning.)
 Refit removed parts of insulation.
 Plug in cable connector on speed sensor.
