Operation Manual / TPL65VA32/33
Maintenance
5
Cleaning the filter silencer
5.2
Page 59
© Copyright 2015 ABB. All rights reserved.
September 2015 HZTL2464_EN Revision C
 Join connecting rods (81269) using screws (81272). When tightening
the screws (81272), ensure that connecting rods (81269) are located
correctly in recesses in filter silencer body (81135). Now tighten
screws (81272) alternately until the following maximum torque is
reached:
Screw
Tightening torque [Nm]
81272 20
 Screw lock nuts (81273) onto screw (81272) and tighten to following
torque:
Lock nut
Tightening torque [Nm]
81273 40
 Fit filter strip (81265).
If provided
