Spare parts
12
View of cartridge group showing part
numbers
12.3
Page 129
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2410_EN Revision E
Part number
Description
21000 Shaft
21002 Piston ring
25000 Compressor wheel
32101 Plain bearing bush
32103 Locking ring
32105 Thrust ring
32106 Thrust bearing
32108 Piston ring
32109 Sealing disc
32110 Compressor-end bearing flange
32111 Auxiliary bearing
32112 Turbine-end bearing flange
32113 Compressor-end socket screw
32114 Turbine-end socket screw
32221 Bearing cover
32222 O-ring
42001 Bearing casing
42002 Socket screw
42008 (in customer spare part set) Socket screw
43001 Partition wall
43012* Metal C-ring
* depends on the turbocharger specification.
